The device is designed primarily for municipal water tap filtration. For home use
HOME ART. & SALES SERVICES AG, Sihleggstrasse 23, 8832 Wollerau - Switzerland
Detachable feeder cable - AC 100-240V, 50-60HZ
TYPE APPLIED FILTERS
Reverse osmosis (RO) membrane 20GPD, (main) carbon filter, mechanical filters, antibacterial filter
From 5 ̊C to 38 ̊C
Membrane - 100 Gallons, ap. 378,5 l
408 (width) x 265 (depth) x 420 (height)
capacity: 9,5 l, usable capacity: ap. 6 litrów
TANK - WATER PRODUCTION TIME
Ap. 30 min
0,6 - 0,8 MPa
OPTIMAL INLET WATER PH
SUITABLE INLET WATER PRESSURE
0.07-0.75 Mpa / 0.70-7.5 Bar
PRODUCT RECOVERY RATE
AUTOMATIC FLUSHING SYSTEM
YES - before and after finishing water purifying process
• AqueenaPro device with filters set • Membrane RO in protective foil – to installation • Power pack • Servicing and installation instruction • Drinking tap water • Shielded water cables • Clump the drain • Key to the membrane cover • Straight feedwater • Clamps for quick installation – 2 pieces • Tap mounting
FILTER REPLACEMENT FREQUENCY
Filter name – Code - Expected date of exchange, counted from the date of installation: •Five-Micron PP filter WT-100-72 every 6 months • Active Carbon filter WT-100-73 every 6 months • Coconut filter WT-100-75 every 12 months • RO Membrane WT-100-15 every 12 months. The table shows only approximate, estimated series of exchanges not their warranty period. To ensure the most optimal filtration you may need to replace filters with greater frequency. Speed and quality of the filtration (the yield of water) is mainly dependent on water pressure, temperature and quality of the filtered water. Thus, reverse osmosis system always generate a recoil water. For Aqueena PRO the ratio is provided 2:1. The device is additionally equipped with a signaling system of light and sound, indicating the need for maintenance. In the case of higher consumption of water (than standard), the device can signal the need for maintenance at other times than the above.
Installation of the unit: Aqueena Pro, the device for purifying water, is designed to be fitted under the sink. Pre-assembly requires some work * carpentry and plumbing work.We recommend preparing the installation site: • The distance between the place of connection and the place of installation of the device should not exceed 1.5 m • The distance from the source of water should not exceed 3 m. • The distance from the outflow of consumed water should not exceed 3 m • The dimensions of the installation site should be consistent with the dimensions of the Aqueena Pro device. It is recommended to install the device near the sink to make the inlet and outlet water hoses easily accessible.* Note: Depending on the installation place and technical possibilities of connecting it to the drainage system, it may be necessary to drill a hole, e,g. in the kitchen worktop. Some additional work to prepare the site and infrastructure for installation /connection of the filter (e.g. specialized drilling of holes in stone, marble or other tops, adaptation of the drainage system, installation of independent water supplies, securing additional connections and valves)may be required.
CE conformity for electrical equipment.
The Declaration of Conformity with Directive 2004/108 / EC on electromagnetic compatibility. Declaration of Conformity with Low Voltage Directive 2006/95/EC. Directive 2002/95/EC (RoHS) on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
Declaration to Directive WEEE 2002/96/EC (Waste of Electrical and Electronic Equipment)
Declaration of Conformity concerning the Regulation (EC) Nº1935/2004 on materials and articles intended to come into contact with food.
